DC Voltage Ranges 200mV, 2000mV, 20V, 200V, 600V
Resolution 0.1mV
Accuracy 0.5%±1
Input Impedence 10MΩ

AC Voltage

(50Hz-500Hz)

 Ranges 200mV, 2000mV, 20V, 200V, 600V
Resolution 0.1mV
Accuracy 1.2%±4(200mV to 20V ranges), 2%±4(200V and 600V ranges)
Input Impedence 10MΩ

DC Current

(through meter)

 Ranges 200μA, 2mA, 20mA, 200mA, 10A
Resolution 0.1μA
Accuracy 1.0%±1 (200μA to 200mA ranges), 3.0%±3 (on 10A range)
Voltage burden 400mV

AC Current

(through meter)

 Ranges 200μA, 2mA, 20mA, 200mA, 10A
Resoltuion 0.1μA
Accuracy 1.5%±4 (200μA to 200mA ranges), 3.5%±4 (on 10A range)
Voltage burden 400mV

Resistance

(ohms)

 Ranges 200Ω, 2kΩ, 20kΩ, 200kΩ, 2MΩ, 20MΩ, 200MΩ
Resolution 0.1Ω
Accuracy 1.0%±4 (200Ω to 2MΩ ranges), 2.0%±4 (20MΩ range), (5.0%-10) + 10 (200MΩ range)
Open circuit voltage 0.3VDC typical, (3.0VDC on 200Ω and 200MΩ ranges)
Diode Test Accuracy 1.5%±3
Test current 1.0mA approx.
Open circuit voltage 3.0VDC typical
